Description
Technical Parameters
Specification:
| Model | Nominal Voltage | Nominal Capacity | Dimensions | Ht.Over Terminal | Weight Approx(kg) | Terminals | |||||||
| L | W | H | |||||||||||
| (v) | (Ah) | in | mm | in | mm | in | mm | in | mm | kg | lb | ||
| STXL100-2 | 2 | 100 | 6.73 | 171 | 2.83 | 72 | 8.07 | 205 | 8.27 | 210 | 5.9 | 13 | B05 |
| STXL200-2 | 2 | 200 | 6.81 | 173 | 4.37 | 111 | 12.95 | 329 | 14.37 | 365 | 13.5 | 29.75 | B05 |
| STXL300-2 | 2 | 300 | 6.73 | 171 | 5.94 | 151 | 12.99 | 330 | 14.41 | 366 | 19.5 | 42.98 | B05 |
| STXL400-2 | 2 | 400 | 8.31 | 211 | 6.93 | 176 | 12.95 | 329 | 14.45 | 367 | 27 | 59.5 | B05 |
| STXL500-2 | 2 | 500 | 9.49 | 241 | 6.77 | 172 | 13.03 | 331 | 14.33 | 364 | 32.8 | 72.29 | B05 |
| STXL600-2 | 2 | 600 | 11.85 | 301 | 6.89 | 175 | 13.03 | 331 | 14.41 | 366 | 38.5 | 84.87 | B05 |
| STXL800-2 | 2 | 800 | 16.14 | 410 | 6.89 | 175 | 12.99 | 330 | 14.37 | 365 | 53 | 116.8 | B05 |
| STXL1000-2 | 2 | 1000 | 18.7 | 475 | 6.85 | 174 | 12.91 | 328 | 14.37 | 365 | 61.5 | 135.6 | B05 |
| STXL1500-2 | 2 | 1500 | 15.79 | 401 | 13.82 | 351 | 13.5 | 343 | 14.88 | 378 | 110 | 242.2 | B05 |
| STXL2000-2 | 2 | 2000 | 19.33 | 491 | 13.82 | 351 | 13.54 | 344 | 15.08 | 383 | 134 | 295 | B05 |
| STXL2500-2 | 2 | 2500 | 28.03 | 712 | 13.89 | 353 | 13.38 | 340 | 15.03 | 382 | 166 | 365.86 | B05 |
| STXL3000-2 | 2 | 3000 | 28.03 | 712 | 13.89 | 353 | 13.38 | 340 | 15.03 | 382 | 190 | 418.76 | B05 |
